IGBT BIPO 600V 3A TO220
STGP3HF60HD is a Transistors - IGBTs - Single manufactured by STMicroelectronics. IGBT BIPO 600V 3A TO220. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C (TJ), package / case TO-220-3, current - collector (ic) (max) 7.5 A.
In Stock: 8,892
| Attribute | Value |
|---|---|
| Product Status | Active |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 7.5 A |
| Current - Collector Pulsed (Icm) | 18 A |
| Vce(on) (Max) @ Vge, Ic | 2.95V @ 15V, 1.5A |
| Power - Max | 38 W |
| Switching Energy | 19µJ (on), 12µJ (off) |
| Input Type | Standard |
| Gate Charge | 12 nC |
| Td (on/off) @ 25°C | 11ns/60ns |
| Test Condition | 400V, 1.5A, 100Ohm, 15V |
| Reverse Recovery Time (trr) | 85 ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220 |
Submit your RFQ for STGP3HF60HD and get a quote within 24 hours.
