CAP ALUM 100UF 20% 35V SMD
35SEV100M8X10.5 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 100UF 20% 35V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - rated 35 V, package / case Radial, Can - SMD.
In Stock: 5,101
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 280 mA @ 120 Hz |
| Ripple Current @ High Frequency | 336 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 35TXV100M10X10.5 | Rubycon | CAP ALUM 100UF 20% 35V SMD | 88% | View |
| MAL215097803E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 100UF 20% 63V SMD | 73% | View |
| EMZR500ARA101MF80G | United Chemi-Con | CAP ALUM 100UF 20% 50V SMD | 72% | View |
| UUQ1C101MCL6GS | Nichicon | CAP ALUM 100UF 20% 16V SMD | 71% | View |
| EEE-FP0J101AP | Panasonic Electronic Components | CAP ALUM 100UF 20% 6.3V SMD | 68% | View |
| UWZ1H101MCL1GS | Nichicon | CAP ALUM 100UF 20% 50V SMD | 61% | View |
