Panasonic Electronic Components
CAP ALUM 560UF 20% 160V SNAP
EET-UQ2C561HA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 560UF 20% 160V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 160 V, package / case Radial, Can - Snap-In.
In Stock: 9,472
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | 355mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.25 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.15 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-UQ2C561HA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 380LX561M180H032 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 180V SNAP | 94% | View |
| LGW2D561MELZ35 | Nichicon | CAP ALUM 560UF 20% 200V SNAP | 92% | View |
| EET-UQ2D561CA | Panasonic Electronic Components | CAP ALUM 560UF 20% 200V SNAP | 90% | View |
| B43601F2567M | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 250V SNAP | 81% | View |
| LKX2D561MESA35 | Nichicon | CAP ALUM 560UF 20% 200V SNAP | 79% | View |
| MAL219356561E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 560UF 20% 400V SNAP | 72% | View |
Submit your RFQ for EET-UQ2C561HA and get a quote within 24 hours.
