CAP ALUM 560UF 20% 50V SMD
UCX1H561MNS1ZD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 560UF 20% 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 135°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 4,446
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 70mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 135°C |
| Operating Temperature | -40°C ~ 135°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 500 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.669" (17.00mm) |
| Surface Mount Land Size | 0.673" L x 0.673" W (17.10mm x 17.10mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
UCX1H561MNS1ZD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UCX1H561MNS1MS | Nichicon | CAP ALUM 560UF 20% 50V SMD | 100% | View |
| UCX1H561MNQ1MS | Nichicon | CAP ALUM 560UF 20% 50V SMD | 100% | View |
| UCX1H561MNJ1MS | Nichicon | CAP ALUM 560UF 20% 50V SMD | 100% | View |
| VUX561M1HTR-1616S | Surge | CAP ALUM 50V POLAR | 100% | View |
| EMXB350ARA561MLH0S | United Chemi-Con | CAP ALUM 560UF 20% 35V SMD | 85% | View |
| EMXB250ARA561MKE0S | United Chemi-Con | CAP ALUM 560UF 20% 25V SMD | 72% | View |
Submit your RFQ for UCX1H561MNS1ZD and get a quote within 24 hours.
