IC MOTOR DRIVER SER 18QFN
ATA6831C-PIQW is a PMIC - Full, Half-Bridge Drivers manufactured by Microchip Technology. IC MOTOR DRIVER SER 18QFN. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 150°C (TJ), voltage - supply 4.75V ~ 5.25V, package / case 18-VFQFN Exposed Pad.
In Stock: 6,492
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Output Configuration | Half Bridge (3) |
| Applications | Bulbs, DC Motors, Resistors |
| Interface | PWM, SPI |
| Load Type | Inductive, Capacitive, Resistive |
| Technology | Power MOSFET |
| Rds On (Typ) | 800mOhm LS, 800mOhm HS |
| Current - Output / Channel | 1A |
| Current - Peak Output | - |
| Voltage - Supply | 4.75V ~ 5.25V |
| Voltage - Load | 5.6V ~ 40V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Features | - |
| Fault Protection | Open Load Detect, Over Temperature, Short Circuit, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 18-VFQFN Exposed Pad |
| Supplier Device Package | 18-VQFN (4x4) |
ATA6831C-PIQW is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ATA6831C-PIQW-1 | Microchip Technology | TRIPLE HALF-BRIDGE DRIVER 18QFN | 100% | View |
| ATA6826C-TUQY-66 | Microchip Technology | IC MOTOR DRIVER 4.75V-5.25V 14SO | 100% | View |
| ATA6826N-TUQY | Microchip Technology | IC MOTOR DRVR 4.75V-5.25V 14SOIC | 100% | View |
| ATA6826C-TUQW | Microchip Technology | IC MOTOR DRIVER DMOS 14SOIC | 96% | View |
| NCV7703CD2R2G | onsemi | IC DVR HALF BRIDGE TRPL 14SOIC | 89% | View |
| IRSM836-015MA | Infineon Technologies | IC MOTOR DRIVER 500V QFN | 53% | View |
Submit your RFQ for ATA6831C-PIQW and get a quote within 24 hours.
