MICROPHONE COND ANALOG NC -55DB
BW-21789-000 is a Microphones manufactured by Knowles. MICROPHONE COND ANALOG NC -55DB. Key specifications: voltage - rated 1.3 V, current - supply 50 µA, size / dimension 0.310" L x 0.218" W (7.87mm x 5.54mm), termination Solder Pads.
In Stock: 6,346
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 100 Hz ~ 4 kHz |
| Sensitivity | -55dB ±4dB @ 74dB SPL |
| S/N Ratio | - |
| Impedance | 3.5 kOhms |
| Voltage - Rated | 1.3 V |
| Voltage Range | 1.3 V ~ 10 V |
| Current - Supply | 50 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.310" L x 0.218" W (7.87mm x 5.54mm) |
| Height (Max) | 0.090" (2.29mm) |
| Shape | Rectangular |
