CAP FILM 0.33UF 5% 3KVDC SCREW
C4BSYBX3330ZALJ is a Film Capacitors manufactured by KEMET. CAP FILM 0.33UF 5% 3KVDC SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage rating - dc 3000V (3kV), package / case Rectangular Box.
In Stock: 4,712
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 0.33 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | 750V |
| Voltage Rating - DC | 3000V (3kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 5.4 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | 1.654" L x 1.181" W (42.00mm x 30.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Termination | Screw Terminals |
| Lead Spacing | 1.004" (25.50mm) |
| Applications | DC Link, DC Filtering; Snubber |
| Ratings | - |
| Features | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| C4BSYBX3330ZBLJ | KEMET | CAP FILM 0.33UF 5% 3KVDC SCREW | 100% | View |
| 334HC2800K2CM6 | Cornell Dubilier / Illinois Capacitor | CAP FILM 0.33UF 800VAC CHAS MT | 99% | View |
| 334LC3700K5LM8 | Cornell Dubilier / Illinois Capacitor | CAP FILM 0.33UF 10% 700VAC SMD | 99% | View |
| MKP386M433250JT8 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.33UF 5% 2.5KVDC SCREW | 97% | View |
| PMB2253330KSP | Nichicon | FILM CAP BOXED LUGS | 97% | View |
| 334LC4102K5LM8 | Cornell Dubilier / Illinois Capacitor | CAP FILM 0.33UF 1KVAC CHAS MT | 95% | View |
Submit your RFQ for C4BSYBX3330ZALJ and get a quote within 24 hours.
