850N - Hammond Manufacturing - Audio Transformers

850N

Hammond Manufacturing

TRANSF AUDIO 150/600 10K/40K IMP

850N is a Audio Transformers manufactured by Hammond Manufacturing. TRANSF AUDIO 150/600 10K/40K IMP. Key specifications: mounting type Chassis Mount, size / dimension 1.700" L x 1.200" W (43.18mm x 30.48mm), termination style Solder Lug, frequency range 20Hz ~ 20kHz.

In Stock: 4,997

Product Attributes

AttributeValue
Product StatusObsolete
Turns Ratio - Primary:Secondary-
Impedance - Primary (Ohms)600, 150/150
Impedance - Secondary (Ohms)40k, 10k/10k
DC Resistance (DCR) - Primary65Ohm
DC Resistance (DCR) - Secondary4.98kOhm
Transformer TypeBroadcast Quality
Frequency Range20Hz ~ 20kHz
Frequency Response-
Voltage - Isolation-
Insertion Loss1dB
Return Loss-
Power Level15dB
Operating Temperature-
Approval Agency-
Mounting TypeChassis Mount
Size / Dimension1.700" L x 1.200" W (43.18mm x 30.48mm)
Height - Seated (Max)1.650" (41.91mm)
Termination StyleSolder Lug

Frequently Asked Questions

850N is a Audio Transformers manufactured by Hammond Manufacturing. TRANSF AUDIO 150/600 10K/40K IMP

The mounting type of 850N is Chassis Mount.

The size of 850N is 1.700" L x 1.200" W (43.18mm x 30.48mm).

The termination type of 850N is Solder Lug.

Yes, 850N is listed as Obsolete. Consider requesting a quote for alternative parts.
