850L - Hammond Manufacturing - Audio Transformers

850L

Hammond Manufacturing

TRANSFR AUDIO 5K/20K 150/600 IMP

850L is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFR AUDIO 5K/20K 150/600 IMP. Key specifications: mounting type Chassis Mount, size / dimension 1.700" L x 1.200" W (43.18mm x 30.48mm), termination style Solder Lug, frequency range 20Hz ~ 20kHz.

In Stock: 2,866

Product Attributes

AttributeValue
Product StatusObsolete
Turns Ratio - Primary:Secondary-
Impedance - Primary (Ohms)20k, 5k/5k
Impedance - Secondary (Ohms)600, 150/150
DC Resistance (DCR) - Primary2.24kOhm
DC Resistance (DCR) - Secondary69Ohm
Transformer TypeBroadcast Quality
Frequency Range20Hz ~ 20kHz
Frequency Response-
Voltage - Isolation-
Insertion Loss1dB
Return Loss-
Power Level15dB
Operating Temperature-
Approval Agency-
Mounting TypeChassis Mount
Size / Dimension1.700" L x 1.200" W (43.18mm x 30.48mm)
Height - Seated (Max)1.650" (41.91mm)
Termination StyleSolder Lug

Frequently Asked Questions

850L is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFR AUDIO 5K/20K 150/600 IMP

The mounting type of 850L is Chassis Mount.

The size of 850L is 1.700" L x 1.200" W (43.18mm x 30.48mm).

The termination type of 850L is Solder Lug.

Yes, 850L is listed as Obsolete. Consider requesting a quote for alternative parts.
