1760H - Hammond Manufacturing - Audio Transformers

1760H

Hammond Manufacturing

TRANSFORMER TUBE GUITAR AMP

1760H is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP. Key specifications: mounting type Chassis Mount, size / dimension 3.710" L x 2.400" W (94.23mm x 60.96mm), termination style Wire Leads, frequency range 70Hz ~ 15kHz.

In Stock: 2

Product Attributes

AttributeValue
Product StatusActive
Turns Ratio - Primary:Secondary40.62:1, 28.72:1, 20.31:1
Impedance - Primary (Ohms)6.6kCT
Impedance - Secondary (Ohms)4, 8, 16
DC Resistance (DCR) - Primary347.8Ohm
DC Resistance (DCR) - Secondary686mOhm, 803mOhm, 1.157Ohm
Transformer TypePush-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range70Hz ~ 15kHz
Frequency Response±1dB
Voltage - Isolation-
Insertion Loss-
Return Loss-
Power Level20W
Operating Temperature-
Approval Agency-
Mounting TypeChassis Mount
Size / Dimension3.710" L x 2.400" W (94.23mm x 60.96mm)
Height - Seated (Max)2.371" (60.22mm)
Termination StyleWire Leads

Frequently Asked Questions

1760H is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP

The mounting type of 1760H is Chassis Mount.

The size of 1760H is 3.710" L x 2.400" W (94.23mm x 60.96mm).

The termination type of 1760H is Wire Leads.
