TRANSFORMER TUBE GUITAR AMP
1760F is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP. Key specifications: mounting type Chassis Mount, size / dimension 3.250" L x 1.687" W (82.55mm x 42.85mm), termination style Wire Leads, frequency range 70Hz ~ 15kHz.
In Stock: 2
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | 29.19:1 |
| Impedance - Primary (Ohms) | 6.95kCT |
| Impedance - Secondary (Ohms) | 4, 8, 16 |
| DC Resistance (DCR) - Primary | 120Ohm |
| DC Resistance (DCR) - Secondary | 171mOhm, 245mOhm, 476mOhm |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output |
| Frequency Range | 70Hz ~ 15kHz |
| Frequency Response | ±1dB |
| Voltage - Isolation | - |
| Insertion Loss | - |
| Return Loss | - |
| Power Level | 15W |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Chassis Mount |
| Size / Dimension | 3.250" L x 1.687" W (82.55mm x 42.85mm) |
| Height - Seated (Max) | 2.058" (52.27mm) |
| Termination Style | Wire Leads |
Submit your RFQ for 1760F and get a quote within 24 hours.
