1760E - Hammond Manufacturing - Audio Transformers

1760E

Hammond Manufacturing

TRANSFORMER TUBE GUITAR AMP

1760E is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP. Key specifications: mounting type Chassis Mount, size / dimension 3.250" L x 2.085" W (82.55mm x 52.96mm), termination style Wire Leads, frequency range 70Hz ~ 15kHz.

In Stock: 2

Product Attributes

AttributeValue
Product StatusActive
Turns Ratio - Primary:Secondary32.61:1
Impedance - Primary (Ohms)8.5kCT
Impedance - Secondary (Ohms)4, 8, 16
DC Resistance (DCR) - Primary150Ohm
DC Resistance (DCR) - Secondary300Ohm, 450mOhm
Transformer TypePush-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range70Hz ~ 15kHz
Frequency Response±1dB
Voltage - Isolation-
Insertion Loss-
Return Loss-
Power Level15W
Operating Temperature-
Approval Agency-
Mounting TypeChassis Mount
Size / Dimension3.250" L x 2.085" W (82.55mm x 52.96mm)
Height - Seated (Max)2.058" (52.27mm)
Termination StyleWire Leads

Frequently Asked Questions

1760E is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP

The mounting type of 1760E is Chassis Mount.

The size of 1760E is 3.250" L x 2.085" W (82.55mm x 52.96mm).

The termination type of 1760E is Wire Leads.
