1760C - Hammond Manufacturing - Audio Transformers

1760C

Hammond Manufacturing

TRANSFORMER TUBE GUITAR AMP

1760C is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP. Key specifications: mounting type Chassis Mount, size / dimension 2.813" L x 1.560" W (71.45mm x 39.62mm), termination style Wire Leads, frequency range 70Hz ~ 15kHz.

In Stock: 11

Product Attributes

AttributeValue
Product StatusActive
Turns Ratio - Primary:Secondary44.61:1
Impedance - Primary (Ohms)5k, 8k
Impedance - Secondary (Ohms)3.2, 8, 16
DC Resistance (DCR) - Primary284.2Ohm
DC Resistance (DCR) - Secondary292mOhm
Transformer TypeSingle Ended Audiophile, Ultra-Linear - Tube Output
Frequency Range70Hz ~ 15kHz
Frequency Response±1dB
Voltage - Isolation-
Insertion Loss-
Return Loss-
Power Level5W
Operating Temperature-
Approval Agency-
Mounting TypeChassis Mount
Size / Dimension2.813" L x 1.560" W (71.45mm x 39.62mm)
Height - Seated (Max)1.746" (44.35mm)
Termination StyleWire Leads

Frequently Asked Questions

1760C is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER TUBE GUITAR AMP

The mounting type of 1760C is Chassis Mount.

The size of 1760C is 2.813" L x 1.560" W (71.45mm x 39.62mm).

The termination type of 1760C is Wire Leads.
