TRANSFORMER AUDIO
140REX is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER AUDIO. Key specifications: mounting type Chassis Mount, size / dimension 1.250" Dia (31.75mm), termination style Screw Terminal, frequency range 20Hz ~ 20kHz.
In Stock: 6,794
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | 2:1 |
| Impedance - Primary (Ohms) | 600CT |
| Impedance - Secondary (Ohms) | 150 |
| DC Resistance (DCR) - Primary | 72.4Ohm |
| DC Resistance (DCR) - Secondary | 18.2Ohm |
| Transformer Type | - |
| Frequency Range | 20Hz ~ 20kHz |
| Frequency Response | ±1dB |
| Voltage - Isolation | 500Vrms |
| Insertion Loss | 1dB Typ |
| Return Loss | 22.5dB Typ |
| Power Level | 10dB |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Chassis Mount |
| Size / Dimension | 1.250" Dia (31.75mm) |
| Height - Seated (Max) | 1.000" (25.40mm) |
| Termination Style | Screw Terminal |
Submit your RFQ for 140REX and get a quote within 24 hours.
