TRANSFORMER AUDIO
140PEX is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER AUDIO. Key specifications: mounting type Chassis Mount, size / dimension 1.250" Dia (31.75mm), termination style Screw Terminal, frequency range 20Hz ~ 20kHz.
In Stock: 6,992
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | 1:1, 1:2, 1:4 |
| Impedance - Primary (Ohms) | 600, 150/150 |
| Impedance - Secondary (Ohms) | 2.4k, 600/600 |
| DC Resistance (DCR) - Primary | 58Ohm |
| DC Resistance (DCR) - Secondary | 190Ohm |
| Transformer Type | - |
| Frequency Range | 20Hz ~ 20kHz |
| Frequency Response | ±1dB |
| Voltage - Isolation | 500Vrms |
| Insertion Loss | 0.8dB Typ |
| Return Loss | 30dB Typ |
| Power Level | 10dB |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Chassis Mount |
| Size / Dimension | 1.250" Dia (31.75mm) |
| Height - Seated (Max) | 1.000" (25.40mm) |
| Termination Style | Screw Terminal |
Submit your RFQ for 140PEX and get a quote within 24 hours.
