TRANSFORMER AUDIO 1KCT/600CT
107J is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER AUDIO 1KCT/600CT. Key specifications: mounting type Through Hole, size / dimension 0.630" L x 0.586" W (16.00mm x 14.88mm), termination style PC Pin, frequency range 300Hz ~ 50kHz.
In Stock: 5
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | 1.29:1 |
| Impedance - Primary (Ohms) | 1kCT |
| Impedance - Secondary (Ohms) | 600CT |
| DC Resistance (DCR) - Primary | 92Ohm |
| DC Resistance (DCR) - Secondary | 70Ohm |
| Transformer Type | Miniature Epoxy Potted |
| Frequency Range | 300Hz ~ 50kHz |
| Frequency Response | ±1.5dB |
| Voltage - Isolation | 100VRMS |
| Insertion Loss | - |
| Return Loss | - |
| Power Level | 150mW |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.630" L x 0.586" W (16.00mm x 14.88mm) |
| Height - Seated (Max) | 0.630" (16.00mm) |
| Termination Style | PC Pin |
