TRANSFORMER AUDIO 20000/1000CT
104K is a Audio Transformers manufactured by Hammond Manufacturing. TRANSFORMER AUDIO 20000/1000CT. Key specifications: mounting type Through Hole, size / dimension 0.860" L x 0.710" W (21.84mm x 18.03mm), termination style PC Pin, frequency range 200Hz.
In Stock: 2,834
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | - |
| Impedance - Primary (Ohms) | 20k |
| Impedance - Secondary (Ohms) | 1kCT |
| DC Resistance (DCR) - Primary | 790Ohm |
| DC Resistance (DCR) - Secondary | 125Ohm |
| Transformer Type | Miniature Epoxy Potted |
| Frequency Range | 200Hz |
| Frequency Response | -1dB |
| Voltage - Isolation | 200V |
| Insertion Loss | 1dB |
| Return Loss | - |
| Power Level | 35mW |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.860" L x 0.710" W (21.84mm x 18.03mm) |
| Height - Seated (Max) | 0.750" (19.05mm) |
| Termination Style | PC Pin |
Submit your RFQ for 104K and get a quote within 24 hours.
