CAP ALUM 6800UF 20% 63V SNAP
861010786021 is a Aluminum Electrolytic Capacitors manufactured by Würth Elektronik. CAP ALUM 6800UF 20% 63V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 63 V, package / case Radial, Can - Snap-In.
In Stock: 3,669
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 4.32 A @ 120 Hz |
| Ripple Current @ High Frequency | 5.5296 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 380LQ682M050H452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 6800UF 20% 50V SNAP | 85% | View |
| LKG1H682MKNS | Nichicon | CAP ALUM 6800UF 20% 50V SLD LUG | 83% | View |
| ESMH101VNN682MA50U | United Chemi-Con | CAP ALUM 6800UF 20% 100V SNAP | 68% | View |
| EKY-160ELL682ML40S | United Chemi-Con | CAP ALUM 6800UF 20% 16V RADIAL | 66% | View |
| MAL205876682E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 6800UF 20% 25V SNAP | 62% | View |
| LKG1C682MESCCK | Nichicon | CAP ALUM 6800UF 20% 16V SNAP | 61% | View |
Submit your RFQ for 861010786021 and get a quote within 24 hours.
