MOSFET 2N-CH 1200V 404A MODULE
CAS300M12BM2 is a Transistors - FETs, MOSFETs - Arrays manufactured by Wolfspeed, Inc.. MOSFET 2N-CH 1200V 404A MODULE. Key specifications: mounting type Chassis Mount, operating temperature 150°C (TJ), package / case Module, Screw Terminals, power - max 1660W.
In Stock: 30
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| FET Type | 2 N-Channel (Half Bridge) |
| FET Feature | Silicon Carbide (SiC) |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Current - Continuous Drain (Id) @ 25°C | 423A (Tc) |
| Rds On (Max) @ Id, Vgs | 5.7mOhm @ 300A, 20V |
| Vgs(th) (Max) @ Id | 2.3V @ 15mA (Typ) |
| Gate Charge (Qg) (Max) @ Vgs | 1025nC @ 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 19.5nF @ 800V |
| Power - Max | 1660W |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module, Screw Terminals |
| Supplier Device Package | Module |
Submit your RFQ for CAS300M12BM2 and get a quote within 24 hours.
