Vishay Beyschlag/Draloric/BC Components
CAP ALUM 3300UF 20% 450V SCREW
MAL250177332E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 3300UF 20% 450V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can - Screw Terminals.
In Stock: 8,807
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 55mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 11.2 A @ 100 Hz |
| Ripple Current @ High Frequency | 16.8 A @ 10 kHz |
| Impedance | 40 mOhms |
| Lead Spacing | 1.122" (28.50mm) |
| Size / Dimension | 2.559" Dia (65.00mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| E37F451CPN332MDB7U | United Chemi-Con | CAP ALUM 3300UF 20% 450V SCREW | 98% | View |
| MAL250136332E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 400V SCREW | 95% | View |
| DCMC332M400CC5F | Cornell Dubilier Electronics (CDE) | CAP ALUM 3300UF 20% 400V SCREW | 92% | View |
| LNU2G332MSEHBN | Nichicon | CAP ALUM 3300UF 20% 400V SCREW | 91% | View |
| PEH200OV4330MB2 | KEMET | CAP ALUM 3300UF 20% 420V SCREW | 90% | View |
| LNC2W332MSEHBN | Nichicon | CAP ALUM 3300UF 20% 450V SCREW | 86% | View |
Submit your RFQ for MAL250177332E3 and get a quote within 24 hours.
