CAP ALUM 3300UF 20% 420V SCREW
PEH200OV4330MB2 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 3300UF 20% 420V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 420 V, package / case Radial, Can - Screw Terminals.
In Stock: 6,205
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 420 V |
| ESR (Equivalent Series Resistance) | 22mOhm @ 100Hz |
| Lifetime @ Temp. | 19000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 14 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 1.260" (32.00mm) |
| Size / Dimension | 3.016" Dia (76.60mm) |
| Height - Seated (Max) | 5.787" (147.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| DCMC332M400CC5F | Cornell Dubilier Electronics (CDE) | CAP ALUM 3300UF 20% 400V SCREW | 97% | View |
| LNU2G332MSEHBN | Nichicon | CAP ALUM 3300UF 20% 400V SCREW | 96% | View |
| LNC2G332MTEH | Nichicon | CAP ALUM 3300UF 20% 400V SCREW | 95% | View |
| LNC2W332MSEHBN | Nichicon | CAP ALUM 3300UF 20% 450V SCREW | 94% | View |
| E37F451CPN332MDB7U | United Chemi-Con | CAP ALUM 3300UF 20% 450V SCREW | 92% | View |
| LNY2V332MSEFBN | Nichicon | CAP ALUM 3300UF 20% 350V SCREW | 92% | View |
