Vishay Beyschlag/Draloric/BC Components
CAP ALUM 82UF 20% 450V SNAP
MAL219367829E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 82UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 9,414
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 82 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 890mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 800 mA @ 100 Hz |
| Ripple Current @ High Frequency | 1.2 A @ 10 kHz |
| Impedance | 490 mOhms |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL225917829E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 82UF 20% 450V SNAP | 91% | View |
| UCS2G820MHD | Nichicon | CAP ALUM 82UF 20% 400V RADIAL | 90% | View |
| 400BXW82MEFR14.5X35 | Rubycon | CAP ALUM 82UF 20% 400V RADIAL | 84% | View |
| EKXJ401ELL820MM25S | United Chemi-Con | CAP ALUM 82UF 20% 400V RADIAL | 84% | View |
| B43504A5826M87 | EPCOS - TDK Electronics | CAP ALUM 82UF 20% 450V SNAP | 74% | View |
| UCS2C820MHD | Nichicon | CAP ALUM 82UF 20% 160V RADIAL | 72% | View |
