CAP ALUM 470UF 20% 63V RADIAL
678D477M063ER5J is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 470UF 20% 63V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 4,976
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 120mOhm @ 20Hz |
| Lifetime @ Temp. | 4000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.19 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.7 A @ 100 kHz |
| Impedance | 38 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL224638471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 63V RADIAL | 83% | View |
| 517D477M100EN6AE3 | Vishay Sprague | CAP ALUM 470UF 20% 100V RADIAL | 72% | View |
| URZ1J471MHD | Nichicon | CAP ALUM 470UF 20% 63V RADIAL | 71% | View |
| B41789K8477Q001 | EPCOS - TDK Electronics | CAP ALUM 470UF 63V RADIAL | 71% | View |
| 672D477F050FV4D | Vishay Sprague | CAP ALUM 470UF 50V RADIAL | 68% | View |
| UBW1K471MHD | Nichicon | CAP ALUM 470UF 20% 80V RADIAL | 68% | View |
Submit your RFQ for 678D477M063ER5J and get a quote within 24 hours.
