CAP ALUM 1000UF 20% 10V RADIAL
678D108M010DM3J is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 1000UF 20% 10V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 10 V, package / case Radial, Can.
In Stock: 7,265
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10 V |
| ESR (Equivalent Series Resistance) | 120mOhm @ 20Hz |
| Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 686 mA @ 120 Hz |
| Ripple Current @ High Frequency | 980 mA @ 100 kHz |
| Impedance | 61 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.161" (29.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 678D108M6R3DG5O | Vishay Sprague | CAP ALUM 1000UF 20% 6.3V RADIAL | 79% | View |
| EKRG160ELL102MK13S | United Chemi-Con | CAP ALUM 1000UF 20% 16V RADIAL | 73% | View |
| B41888C4108M000 | EPCOS - TDK Electronics | CAP ALUM 1000UF 20% 16V RADIAL | 68% | View |
| B41866C5108M000 | EPCOS - TDK Electronics | CAP ALUM 1000UF 20% 25V RADIAL | 65% | View |
| MAL211915102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 16V AXIAL | 61% | View |
| 604D102F050GL7 | Vishay Sprague | CAP ALUM 1000UF 50V AXIAL | 56% | View |
Submit your RFQ for 678D108M010DM3J and get a quote within 24 hours.
