CAP ALUM 1000UF 12V RADIAL
672D108F012DS3J is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 1000UF 12V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 12 V, package / case Radial, Can.
In Stock: 6,106
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | -10%, +50% |
| Voltage - Rated | 12 V |
| ESR (Equivalent Series Resistance) | 150mOhm @ 120Hz |
| Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.645 A @ 120 Hz |
| Ripple Current @ High Frequency | 235 mA @ 100 kHz |
| Impedance | 60 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.791" (45.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEU-FC1A102LJ | Panasonic Electronic Components | CAP ALUM 1000UF 20% 10V RADIAL | 71% | View |
| MAL213634102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 10V RADIAL | 70% | View |
| 672D108F015ET3D | Vishay Sprague | CAP ALUM 1000UF 15V RADIAL | 66% | View |
| MAL213661102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 50V RADIAL | 59% | View |
| EEU-FC1C102SB | Panasonic Electronic Components | CAP ALUM 1000UF 20% 16V RADIAL | 56% | View |
| EEU-FK1C102B | Panasonic Electronic Components | CAP ALUM 1000UF 20% 16V RAD TH | 55% | View |
