IC SWITCH QUAD SPDT 16SOT-23
TMUX1574DYYR is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Texas Instruments. IC SWITCH QUAD SPDT 16SOT-23. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TA), package / case SOT-23-16 Thin, SOT-23 Variant, number of circuits 4.
In Stock: 6,650
| Attribute | Value |
|---|---|
| Product Status | Active |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 4.5Ohm |
| Channel-to-Channel Matching (ΔRon) | 70mOhm |
| Voltage - Supply, Single (V+) | 1.5V ~ 5.5V |
| Voltage - Supply, Dual (V±) | 1.5V ~ 5.5V |
| Switch Time (Ton, Toff) (Max) | 35µs, 95ns |
| -3db Bandwidth | 2GHz |
| Charge Injection | 3.5pC |
| Channel Capacitance (CS(off), CD(off)) | 3.5pF, 3.5pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Crosstalk | -90dB @ 100kHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-16 Thin, SOT-23 Variant |
| Supplier Device Package | 16-SOT-23-THIN |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TMUX1574RSVR | Texas Instruments | IC SWITCH SPDT QUAD 16UQFN | 100% | View |
| TMUX1574PWR | Texas Instruments | IC SWITCH SPDT QUAD 16TSSOP | 100% | View |
| TMUX1511PWR | Texas Instruments | IC SWITCH SPST QUAD 14TSSOP | 77% | View |
| TMUX1511RSVR | Texas Instruments | IC SWITCH SPST QUAD 16UQFN | 77% | View |
| SN3257QDYYRQ1 | Texas Instruments | 2:1 (SPDT), 4-CHANNEL SWITCH WIT | 59% | View |
| SN3257QPWRQ1 | Texas Instruments | PRECISION ANALOG MULTIPLEXER | 59% | View |
