PC95PQ65/54-Z
FERRITE CORE PQ 13.5UH 2PC SET
PC95PQ65/54-Z is a Ferrite Cores manufactured by TDK Corporation. FERRITE CORE PQ 13.5UH 2PC SET. Key specifications: supplier device package PQ 65 x 54, material PC95, tolerance ±25%.
In Stock: 1
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Core Type | PQ |
| Supplier Device Package | PQ 65 x 54 |
| Material | PC95 |
| Diameter | - |
| Inductance Factor (Al) | 13.5 µH |
| Tolerance | ±25% |
| Gap | Ungapped |
| Effective Permeability (µe) | - |
| Initial Permeability (µi) | - |
| Core Factor (ΣI/A) mm<sup>-1</sup> | 0.21 |
| Effective Length (le) mm | 123 |
| Effective Area (Ae) mm² | 597 |
| Minimum Core Cross Section (Amin) mm² | - |
| Effective Magnetic Volume (Ve) mm³ | 73552 |
| Finish | Uncoated |
| Height | 2.106" (53.50mm) |
| Length | 2.559" (65.00mm) |
| Width | 1.772" (45.00mm) |
Frequently Asked Questions
PC95PQ65/54-Z is a Ferrite Cores manufactured by TDK Corporation. FERRITE CORE PQ 13.5UH 2PC SET
The package type of PC95PQ65/54-Z is PQ 65 x 54.
The material of PC95PQ65/54-Z is PC95.
The tolerance of PC95PQ65/54-Z is ±25%.
