ULTRA WIDE BAND FR4 ANTENNA 3-5G
PCUWB01.01.0500G is a RF Antennas manufactured by Taoglas Limited. ULTRA WIDE BAND FR4 ANTENNA 3-5G. Key specifications: mounting type Adhesive, termination SMA Male, frequency range 3.1GHz ~ 5GHz, 6.2GHz ~ 8GHz, 8GHz ~ 10.3GHz.
In Stock: 82
| Attribute | Value |
|---|---|
| Product Status | Active |
| RF Family/Standard | - |
| Frequency Group | SHF (f > 4GHz) |
| Frequency (Center/Band) | 4.05GHz, 7.1GHz, 9.15GHz |
| Frequency Range | 3.1GHz ~ 5GHz, 6.2GHz ~ 8GHz, 8GHz ~ 10.3GHz |
| Antenna Type | Module |
| Number of Bands | 3 |
| VSWR | 2, 3 |
| Return Loss | -4dB, -6dB, -8dB |
| Gain | 7.5dBi, 4.1dBi, 4.1dBi |
| Power - Max | - |
| Features | Cable - 500mm |
| Termination | SMA Male |
| Ingress Protection | - |
| Mounting Type | Adhesive |
| Height (Max) | 0.394" (10.00mm) |
| Applications | UWB |
Submit your RFQ for PCUWB01.01.0500G and get a quote within 24 hours.
