RES 0.005 OHM 1W 1206 WIDE
PRL1632-R005-F-T1 is a Chip Resistor - Surface Mount manufactured by Susumu. RES 0.005 OHM 1W 1206 WIDE. Key specifications: operating temperature -55°C ~ 125°C, package / case Wide 1206 (3216 Metric), 0612, size / dimension 0.063" L x 0.126" W (1.60mm x 3.20mm), power (watts) 1W.
In Stock: 4,024
| Attribute | Value |
|---|---|
| Product Status | Active |
| Resistance | 5 mOhms |
| Tolerance | ±1% |
| Power (Watts) | 1W |
| Composition | Thin Film |
| Features | Current Sense |
| Temperature Coefficient | 0/ +350ppm/°C |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | Wide 1206 (3216 Metric), 0612 |
| Supplier Device Package | 1206 |
| Ratings | - |
| Size / Dimension | 0.063" L x 0.126" W (1.60mm x 3.20mm) |
| Height - Seated (Max) | 0.024" (0.60mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| RL3264L4-R005-F | Susumu | RES 0.005 OHM 1% 1W 2512 | 86% | View |
| MLFM1FTC5M10 | Stackpole Electronics Inc | RES, MELF, 0207, 5.1 MOHM, 1%, 5 | 84% | View |
| RG3216P-5004-B-T5 | Susumu | RES 5M OHM 0.1% 1/4W 1206 | 69% | View |
| RG3216P-5004-B-T1 | Susumu | RES 5M OHM 0.1% 1/4W 1206 | 69% | View |
| MCA1206MD5004BP100 | Vishay Beyschlag/Draloric/BC Components | MCA 1206-25 0.1% AT P1 5M0 | 69% | View |
| RL7520WT-R005-G | Susumu | RES 0.005 OHM 2W 3008 WIDE | 66% | View |
