CAP ALUM POLY HYB 470UF 16V SMD
HBV471M1CTR-1010S is a Aluminum - Polymer Capacitors manufactured by SURGE. CAP ALUM POLY HYB 470UF 16V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can - SMD.
In Stock: 7,132
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | - |
| Applications | General Purpose |
| Features | - |
| Ripple Current @ Low Frequency | 250 mA @ 120 Hz |
| Ripple Current @ High Frequency | 2.5 A @ 100 kHz |
| Impedance | 20 mOhms |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| HHXB160ARA471MJA0G | United Chemi-Con | CAP ALUM POLY HYB 470UF 16V SMD | 99% | View |
| HHXA160ARA471MJA0G | United Chemi-Con | CAP ALUM POLY HYB 470UF 16V SMD | 94% | View |
| HHXD160ARA471MJA0G | United Chemi-Con | CAP ALUM HYBRD 470UF 20% 16V SMD | 92% | View |
| 35PHV470M10X16.5 | Rubycon | CAP ALUM POLY HYB 470UF 35V SMD | 62% | View |
| EEH-ZS1E471P | Panasonic Electronic Components | CAP POLYMER HYBRID 470UF 25V SMD | 61% | View |
| EEH-ZS1E471V | Panasonic Electronic Components | CAP POLYMER HYBRID 470UF 25V SMD | 61% | View |
Submit your RFQ for HBV471M1CTR-1010S and get a quote within 24 hours.
