Panasonic Electronic Components
CAP POLYMER HYBRID 470UF 25V SMD
EEH-ZS1E471P is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP POLYMER HYBRID 470UF 25V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - rated 25 V, package / case Radial, Can - SMD.
In Stock: 6,120
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 14mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 525 mA @ 100 Hz |
| Ripple Current @ High Frequency | 3.5 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.504" (12.80mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEH-ZS1E471V | Panasonic Electronic Components | CAP POLYMER HYBRID 470UF 25V SMD | 100% | View |
| EEH-ZS1V471P | Panasonic Electronic Components | CAP ALUM POLY 470UF 20% 35V SMD | 83% | View |
| EEH-ZS1V471V | Panasonic Electronic Components | CAP ALUM POLY 470UF 20% 35V SMD | 83% | View |
| B40921A7477M100 | EPCOS - TDK Electronics | CAP ALUM POLY HYB 470UF 35V SMD | 83% | View |
| EEH-ZU1V471P | Panasonic Electronic Components | CAP ALUM POLY HYB 470UF 35V SMD | 68% | View |
| 35PHV470M10X16.5 | Rubycon | CAP ALUM POLY HYB 470UF 35V SMD | 63% | View |
Submit your RFQ for EEH-ZS1E471P and get a quote within 24 hours.
