IC PWR DRVR N-CH 1:1 5PENTAWATT
VN820 is a PMIC - Power Distribution Switches, Load Drivers manufactured by STMicroelectronics. IC PWR DRVR N-CH 1:1 5PENTAWATT. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C (TJ), voltage - supply (vcc/vdd) Not Required, package / case Pentawatt-5 (Vertical, Bent and Staggered Leads).
In Stock: 6,306
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 5.5V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 9A |
| Rds On (Typ) | 40mOhm (Max) |
| Input Type | Non-Inverting |
| Features | Auto Restart, Status Flag |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | 5-PENTAWATT |
| Package / Case | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
VN820 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| VN06-12-E | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
| VN820(012Y) | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
| VN820-11-E | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
| VN06-E | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
| VN820(011Y) | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
| VN06-11-E | STMicroelectronics | IC PWR DRVR N-CH 1:1 5PENTAWATT | 100% | View |
Submit your RFQ for VN820 and get a quote within 24 hours.
