HIGH POWER DENSITY 600 V HALF-BR
MASTERGAN5 is a PMIC - Full, Half-Bridge Drivers manufactured by STMicroelectronics. HIGH POWER DENSITY 600 V HALF-BR. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 3.3V ~ 15V, package / case 31-VQFN Exposed Pad.
In Stock: 10
| Attribute | Value |
|---|---|
| Product Status | Active |
| Output Configuration | Half Bridge |
| Applications | DC-DC Converters |
| Interface | Logic |
| Load Type | Inductive, Capacitive, Resistive |
| Technology | - |
| Rds On (Typ) | 450mOhm |
| Current - Output / Channel | 4A |
| Current - Peak Output | 4A |
| Voltage - Supply | 3.3V ~ 15V |
| Voltage - Load | 3.3V ~ 15V |
| Operating Temperature | -40°C ~ 125°C |
| Features | - |
| Fault Protection | Over Temperature, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 31-VQFN Exposed Pad |
| Supplier Device Package | 31-QFN (9x9) |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MP6610GJ-Z | Monolithic Power Systems Inc. | 55V, 3A, HALF-BRIDGE POWER DRIVE | 82% | View |
| MP6610GS-P | Monolithic Power Systems Inc. | 55V, 3A, HALF-BRIDGE POWER DRIVE | 82% | View |
| P9167NRGI8 | Renesas Electronics America Inc | IC PMIC POWER MODULE 6A 12QFN | 81% | View |
| MC33HB2000EK | NXP USA Inc. | H-BRIDGE SPI BRUSHED DC MOTOR | 66% | View |
| MC33HB2000EKR2 | NXP USA Inc. | H-BRIDGE SPI BRUSHED DC MOTOR | 66% | View |
| MPQ8039GN-AEC1-Z | Monolithic Power Systems Inc. | IC HALF-BRIDGE PWM 8-SOIC | 64% | View |
Submit your RFQ for MASTERGAN5 and get a quote within 24 hours.
