HIGH POWER DENSITY 600V HALF BRI
MASTERGAN4 is a PMIC - Full, Half-Bridge Drivers manufactured by STMicroelectronics. HIGH POWER DENSITY 600V HALF BRI. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 3.3V ~ 15V, package / case 31-VQFN Exposed Pad.
In Stock: 10
| Attribute | Value |
|---|---|
| Product Status | Active |
| Output Configuration | Half Bridge |
| Applications | General Purpose |
| Interface | Logic |
| Load Type | Capacitive and Resistive |
| Technology | - |
| Rds On (Typ) | 225mOhm LS, 225mOhm HS |
| Current - Output / Channel | 6.5A |
| Current - Peak Output | 6.5A |
| Voltage - Supply | 3.3V ~ 15V |
| Voltage - Load | 3.3V ~ 15V |
| Operating Temperature | -40°C ~ 125°C |
| Features | Bootstrap Circuit |
| Fault Protection | Over Temperature, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 31-VQFN Exposed Pad |
| Supplier Device Package | 31-QFN (9x9) |
