CAP ALUM 470UF 20% 400V SNAP
400SXG470MEFCSN35X40 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 470UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 7,490
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.9 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.66 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 420MXH470MEFC30X45 | Rubycon | CAP ALUM 470UF 20% 420V SNAP | 95% | View |
| EKMH451VNN471MA63U | United Chemi-Con | CAP ALUM 470UF 20% 450V SNAP | 92% | View |
| 200VXG470MEFCSN22X35 | Rubycon | CAP ALUM 470UF 20% 200V SNAP | 77% | View |
| 160TXW470MEFR18X35 | Rubycon | CAP ALUM 470UF 20% 160V RADIAL | 70% | View |
| LAR2D471MELZ30 | Nichicon | CAP ALUM 470UF 20% 200V SNAP | 69% | View |
| MAL212026471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 25V AXIAL | 64% | View |
Submit your RFQ for 400SXG470MEFCSN35X40 and get a quote within 24 hours.
