CAP ALUM 330UF 20% 25V RADIAL
25ZLS330MEFC8X11.5 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 330UF 20% 25V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can.
In Stock: 2,000
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 6000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 495 mA @ 120 Hz |
| Ripple Current @ High Frequency | 900 mA @ 100 kHz |
| Impedance | 62 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPM1E331MPD1TD | Nichicon | CAP ALUM 330UF 20% 25V RADIAL | 89% | View |
| 860160475020 | Würth Elektronik | CAP ALUM 330UF 20% 25V RADIAL | 84% | View |
| MALREKE00DD333FG0K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 330UF 20% 35V RADIAL | 84% | View |
| 35RX30330M10X16 | Rubycon | CAP ALUM 330UF 20% 35V RADIAL | 80% | View |
| REF0812331M016K | KYOCERA AVX | CAP ALUM 330UF 20% 16V RADIAL TH | 80% | View |
| URZ2A331MHD | Nichicon | CAP ALUM 330UF 20% 100V RADIAL | 74% | View |
Submit your RFQ for 25ZLS330MEFC8X11.5 and get a quote within 24 hours.
