CAP ALUM 680UF 20% 220V SNAP
220VXG680MEFCSN35X25 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 680UF 20% 220V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 220 V, package / case Radial, Can - Snap-In.
In Stock: 2,964
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 680 µF |
| Tolerance | ±20% |
| Voltage - Rated | 220 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.58 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.37 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPT2D681MRD | Nichicon | CAP ALUM 680UF 20% 200V RADIAL | 96% | View |
| MAL215982681E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 680UF 20% 200V SNAP | 93% | View |
| LAQ2D681MELB30 | Nichicon | CAP ALUM 680UF 20% 200V SNAP | 92% | View |
| LKX2E681MESB40 | Nichicon | CAP ALUM 680UF 20% 250V SNAP | 92% | View |
| 200MXC680MEFCSN30X30 | Rubycon | CAP ALUM 680UF 20% 200V SNAP | 91% | View |
| EKMR201VSN681MP35S | United Chemi-Con | CAP ALUM 680UF 20% 200V SNAP | 89% | View |
Submit your RFQ for 220VXG680MEFCSN35X25 and get a quote within 24 hours.
