DFN1010-6L, MOSFET
PJQ1820_R1_00001 is a Transistors - FETs, MOSFETs - Arrays manufactured by Panjit International Inc.. DFN1010-6L, MOSFET. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 6-UFDFN, power - max 400mW (Ta).
In Stock: 5,000
| Attribute | Value |
|---|---|
| Product Status | Active |
| FET Type | 2 N-Channel (Dual) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 800mA (Ta) |
| Rds On (Max) @ Id, Vgs | 300mOhm @ 500mA, 4.5V |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 1.1nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 46pF @ 10V |
| Power - Max | 400mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN |
| Supplier Device Package | DFN1010-6L |
Submit your RFQ for PJQ1820_R1_00001 and get a quote within 24 hours.
