Panasonic Electronic Components
MOSFET 2N-CH 30V 16A/46A 8-HSO
SC8673040L is a Transistors - FETs, MOSFETs - Arrays manufactured by Panasonic Electronic Components. MOSFET 2N-CH 30V 16A/46A 8-HSO. Key specifications: mounting type Surface Mount, operating temperature 150°C (TJ), package / case 8-PowerSMD, Flat Leads, power - max 1.7W, 2.5W.
In Stock: 2,987
| Attribute | Value |
|---|---|
| Product Status | Active |
| FET Type | 2 N-Channel (Dual) Asymmetrical |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 16A, 46A |
| Rds On (Max) @ Id, Vgs | 10mOhm @ 8A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 5.85mA |
| Gate Charge (Qg) (Max) @ Vgs | 6.3nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1092pF @ 10V |
| Power - Max | 1.7W, 2.5W |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerSMD, Flat Leads |
| Supplier Device Package | HSO8-F3-B |
