Panasonic Electronic Components
CAP ALUM 56UF 20% 80V RADIAL
EEU-FS1K560 is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 56UF 20% 80V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 80 V, package / case Radial, Can.
In Stock: 4,923
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 56 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 6000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 343 mA @ 120 Hz |
| Ripple Current @ High Frequency | 490 mA @ 100 kHz |
| Impedance | 160 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 63ZL56MEFCT78X11.5 | Rubycon | CAP ALUM 56UF 20% 63V RADIAL | 78% | View |
| EEU-FM1H560H | Panasonic Electronic Components | CAP ALUM 56UF 20% 50V RADIAL | 78% | View |
| 50ZLJ56MT16.3X11 | Rubycon | CAP ALUM 56UF 20% 50V RADIAL | 77% | View |
| MAL213658569E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 56UF 20% 63V RADIAL | 61% | View |
| 35ZL56MEFCT16.3X11 | Rubycon | CAP ALUM 56UF 20% 35V RADIAL | 60% | View |
| EKHE451ELL560MK35S | United Chemi-Con | RADIAL ALUMINUM ELECTROLYTIC CAP | 55% | View |
