Panasonic Electronic Components
CAP ALUM 47UF 20% 250V RADIAL
EEU-EE2E470S is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 47UF 20% 250V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can.
In Stock: 8,212
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 490 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.4 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UCY2V470MHD1TO | Nichicon | CAP ALUM 47UF 20% 350V RADIAL | 81% | View |
| EEU-EE2V470 | Panasonic Electronic Components | CAP ALUM 47UF 20% 350V RADIAL | 77% | View |
| UCS2W470MHD | Nichicon | CAP ALUM 47UF 20% 450V RADIAL | 74% | View |
| EEU-ED2C470 | Panasonic Electronic Components | CAP ALUM 47UF 20% 160V RADIAL | 60% | View |
| 672D476H040CD2D | Vishay Sprague | CAP ALUM 47UF 40V RADIAL | 56% | View |
| PEG124MB247VQE4 | KEMET | CAP ALUM 47UF 63V AXIAL | 56% | View |
Submit your RFQ for EEU-EE2E470S and get a quote within 24 hours.
