Panasonic Electronic Components
CAP ALUM 82UF 20% 200V RADIAL
EEU-EE2D820S is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 82UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 7,489
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 82 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 511 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.46 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UCS2E820MHD1TN | Nichicon | CAP ALUM 82UF 20% 250V RADIAL | 85% | View |
| 350BXC82MEFC18X25 | Rubycon | CAP ALUM 82UF 20% 350V RADIAL | 78% | View |
| 381LX820M350H012 | Cornell Dubilier Electronics (CDE) | CAP ALUM 82UF 20% 350V SNAP | 68% | View |
| 160TXW82MEFR8X35 | Rubycon | CAP ALUM 82UF 20% 160V RADIAL TH | 68% | View |
| 861021483005 | Würth Elektronik | CAP ALUM 82UF 20% 450V SNAP | 64% | View |
| MAL215969829E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 82UF 20% 500V SNAP | 62% | View |
Submit your RFQ for EEU-EE2D820S and get a quote within 24 hours.
