CAP ALUM 82UF 20% 160V RADIAL TH
160TXW82MEFR8X35 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 82UF 20% 160V RADIAL TH. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 160 V, package / case Radial, Can.
In Stock: 9,633
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 82 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 430 mA @ 120 Hz |
| Ripple Current @ High Frequency | 602 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 1.476" (37.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPJ2A820MHD6 | Nichicon | CAP ALUM 82UF 20% 100V RADIAL | 80% | View |
| B43255A9826M | EPCOS - TDK Electronics | CAP ALUM 82UF 20% 400V SNAP | 66% | View |
| B43504A5826M60 | EPCOS - TDK Electronics | CAP ALUM 82UF 20% 450V SNAP | 62% | View |
| 63ZLH82MEFCTA8X11.5 | Rubycon | CAP ALUM 82UF 20% 63V RADIAL | 55% | View |
| UCS2E820MHD1TN | Nichicon | CAP ALUM 82UF 20% 250V RADIAL | 55% | View |
| 860080473005 | Würth Elektronik | CAP ALUM 82UF 20% 25V RADIAL | 54% | View |
