Panasonic Electronic Components
CAP ALUM 3300UF 20% 10V RADIAL
EEU-EB1A332B is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 3300UF 20% 10V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 10 V, package / case Radial, Can.
In Stock: 7,107
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 802 mA @ 120 Hz |
| Ripple Current @ High Frequency | 922.3 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| URZ0J332MHD1CV | Nichicon | CAP ALUM 6.3V POLAR | 83% | View |
| 338TMA6R3M | Cornell Dubilier Knowles | ELECTROLYTIC/IC | 83% | View |
| UKA0J332MHD | Nichicon | CAP ALUM 3300UF 20% 6.3V RADIAL | 80% | View |
| 10YXF3300MEFC12.5X25 | Rubycon | CAP ALUM 3300UF 20% 10V RADIAL | 74% | View |
| MAL214895333E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 16V RADIAL | 70% | View |
| MAL214056332E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 25V RADIAL | 50% | View |
