CAP ALUM 3300UF 20% 6.3V RADIAL
UKA0J332MHD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3300UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 7,493
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 910 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.0465 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKA0J332MHD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| URZ0J332MHD1CV | Nichicon | CAP ALUM 6.3V POLAR | 97% | View |
| ECA-0JHG332B | Panasonic Electronic Components | CAP ALUM 3300UF 20% 6.3V RADIAL | 96% | View |
| UVZ0J332MPD1CA | Nichicon | CAP ALUM 6.3V POLAR | 96% | View |
| EKMQ350ELL332MLN3S | United Chemi-Con | CAP ALUM 3300UF 20% 35V RADIAL | 57% | View |
| MAL214056332E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 25V RADIAL | 54% | View |
| MAL213696336E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 25V RADIAL | 51% | View |
Submit your RFQ for UKA0J332MHD and get a quote within 24 hours.
3J LIMITED
