Panasonic Electronic Components
CAP ALUM 560UF 20% 160V SNAP
EET-UQ2C561BA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 560UF 20% 160V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 160 V, package / case Radial, Can - Snap-In.
In Stock: 1,118
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | 355mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.25 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.15 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-UQ2C561BA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SLPX561M200A7P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 200V SNAP | 92% | View |
| B43634A2567M000 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 200V SNAP | 91% | View |
| B43504E2567M002 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 200V SNAP | 80% | View |
| B43252A2567M | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 200V SNAP | 80% | View |
| EGPA101ELL561ML40S | United Chemi-Con | CAP ALUM 560UF 20% 100V RADIAL | 70% | View |
| B43508A9567M60 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 400V SNAP | 67% | View |
Submit your RFQ for EET-UQ2C561BA and get a quote within 24 hours.
