Panasonic Electronic Components
CAP ALUM 330UF 20% 420V SNAP
EET-HC2S331KA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 330UF 20% 420V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 420 V, package / case Radial, Can - Snap-In.
In Stock: 7,233
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 420 V |
| ESR (Equivalent Series Resistance) | 553mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.42 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.988 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-HC2S331KA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LQS2V331MELB30 | Nichicon | CAP ALUM 330UF 20% 350V SNAP | 87% | View |
| LGN2V331MELZ45 | Nichicon | CAP ALUM 330UF 20% 350V SNAP | 87% | View |
| EKMQ251VSN331MQ25S | United Chemi-Con | CAP ALUM 330UF 20% 250V SNAP | 78% | View |
| 35ZLG330MEFC10X16 | Rubycon | CAP ALUM 330UF 20% 35V RADIAL | 68% | View |
| 381LX331M200A202 | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 200V SNAP | 66% | View |
| SEK331M100ST | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 100V RADIAL | 56% | View |
Submit your RFQ for EET-HC2S331KA and get a quote within 24 hours.
