Panasonic Electronic Components
CAP ALUM 560UF 20% 250V SNAP
EET-HC2E561HF is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 560UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 8,580
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | 296mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.5 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.1 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-HC2E561HF is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LGU2D561MELZ | Nichicon | CAP ALUM 560UF 20% 200V SNAP | 86% | View |
| 100ZLH560MEFCGC18X31.5 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 73% | View |
| 100ZL560MEFC18X35.5 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 72% | View |
| 80ZLJ560M16X31.5 | Rubycon | CAP ALUM 560UF 20% 80V RADIAL | 70% | View |
| EKZE350EMC561MJ25S | United Chemi-Con | CAP ALUM 560UF 20% 35V RADIAL | 70% | View |
| 50YXG560MEFC12.5X25 | Rubycon | CAP ALUM 560UF 20% 50V RADIAL | 69% | View |
Submit your RFQ for EET-HC2E561HF and get a quote within 24 hours.
