Panasonic Electronic Components
CAP ALUM 1800UF 20% 200V SNAP
EET-HC2D182KA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 1800UF 20% 200V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can - Snap-In.
In Stock: 5,081
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 1800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | 111mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.08 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.312 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.850" (47.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-HC2D182KA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 381LX182M200A452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 1800UF 20% 200V SNAP | 94% | View |
| 50YXH1800MEFC18X31.5 | Rubycon | CAP ALUM 1800UF 20% 50V RADIAL | 67% | View |
| 63ZLH1800MEFC18X35.5 | Rubycon | CAP ALUM 1800UF 20% 63V RADIAL | 66% | View |
| LGU2A182MELB | Nichicon | CAP ALUM 1800UF 20% 100V SNAP | 60% | View |
| KY35VB182M18X20LL | United Chemi-Con | CAP ALUM 1800UF 20% 35V RADIAL | 55% | View |
| 25YXG1800MEFC12.5X30 | Rubycon | CAP ALUM 1800UF 20% 25V RADIAL | 51% | View |
Submit your RFQ for EET-HC2D182KA and get a quote within 24 hours.
