CAP ALUM 1800UF 20% 100V SNAP
LGU2A182MELB is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1800UF 20% 100V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can - Snap-In.
In Stock: 20
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.27 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.6105 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEU-TP1V182 | Panasonic Electronic Components | CAP ALUM 1800UF 20% 35V RADIAL | 75% | View |
| KY35VB182M18X20LL | United Chemi-Con | CAP ALUM 1800UF 20% 35V RADIAL | 70% | View |
| 35YXH1800MEFC12.5X40 | Rubycon | CAP ALUM 1800UF 20% 35V RADIAL | 70% | View |
| EKYB350ELL182MK30S | United Chemi-Con | CAP ALUM 1800UF 20% 35V RADIAL | 70% | View |
| 50YXH1800MEFC18X31.5 | Rubycon | CAP ALUM 1800UF 20% 50V RADIAL | 70% | View |
| B41866C5188M000 | EPCOS - TDK Electronics | CAP ALUM 1800UF 20% 25V RADIAL | 61% | View |
